適用范圍
1、爆炸性氣體環境：1區、2區
2、場所中危險氣體或蒸氣：IIA、IIB、IIC
3、溫度組別：T1～T6
4、戶內、戶外（防護等級IP54, 可達IP65)
Applying scope
1、Explosive gas atmospheres:Zone 1＆2
2、Dangerous gases or vapors zone: IIA、IIB、IIC
3、Temperature classes:T1～T6
4、 Indoor and outdoor (IP 54,It could be designed as IP65 according to user′s requirements)
產品特點
1、適用于額定電壓380V或220V，額定電流9、16、20、32、40A的線路中，作為連續手持工具及照明燈電源
2、鑄鋁合金外殼，表面噴塑
3、插座上帶有分、合指示
4、插座的接地觸頭比主觸頭長，使主觸頭未接通前先將地線接通
5、在拔脫插頭時，最后分?jǐn)嘟拥鼐€，以保證安全
6、插銷與開關制成聯鎖結構，當插頭插入后，插頭上轉套向右旋轉至一定的角度，插座內的開關即閉合，同時插銷不能拔脫。 反之，將轉套向左旋轉至一定有角度，則開關分?jǐn)啵缓蟛拍馨蔚舨孱^
7、插頭上設有防護蓋，在插頭拔脫后，防護蓋將插座遮蔽，以免外物侵入
8、鋼管或電纜布線，電纜布線須配電纜夾緊密封接頭
Features
1、 Suitable for connecting portable portable tool or lighting fixture to supply power in circuits with rated voltage of 380V or 220V and rated current of 9,16,20,32 or 40A
2、Enclosure is made of casting aluminium alloy ,surface is sprayed with plastics
3、With ON/OFF indication on the socket
4、Earth pin is longer than main pin, before power is on, the earth pin works
5、When pulling out the plug, the earth pin could not be disconnected before main pin is disconnected to ensure safely
6、The plug and socket is interlocked with switch. When insert is plug into socket and rotate sheath in right direction to certain angle, the switch can be opened and the plug could be pulled out
7、With guarding cover on the socket, after plug being pulled out, the cover could protect the socket from foreign articles
8、Wiring with conduit or cable,For cable, it should be fitted with explosion-protected cable sealing connector
|
|
 |
