BAZ51系列防爆鎮流器(IIB、IIC、e)
|
|
| |
|
適用范圍
1、1區、2區危險場所。
2、ⅡA、ⅡB、ⅡC類爆炸性氣體環境。
＊要求ⅡC類或增安型請注明。
Application
1、Can be used in Zone 1 and Zone 2 dangerous places.
2、Can be used in ⅡA、ⅡB、ⅡC group explosive atmosphere.
＊Please note if want ⅡC or safety-increased type. |
產品特點
1、鑄鋁合金外殼，表面噴塑。
2、可直接吊裝燈具。
3、鋼管或電纜布線均可。
4、可按要求做成補償器。
5、符合GB3836-2000，IEC60079標準要求。
Features
1、The shell is made of diecasted Al-alloy with plastic-sprayed surface.
2、Able to directly hung lamp.
3、Suitable for steel pipe and cable siring.
4、Can add electricity capacity as required.
5、Suitable for GB3836-2000, IEC60079 standard request. |
|
 |
| |
|
 |
| |
|
| 主要技術參數 Main technical parameters |
|
型 號 |
額定電壓(V) |
額定功率(W) |
防爆標志 |
防護等級 |
電纜外徑(F,mm) |
出線口螺紋(G″) |
外殼類型 |
質量 |
BAZ51-G125 |
|
125 |
|
|
|
|
Ⅰ |
5.5 |
BAZ51-G250 |
|
250 |
|
|
|
|
Ⅲ |
6.5 |
BAZ51-G400 |
|
400 |
|
|
|
|
Ⅲ |
8 |
BAZ51-N110 |
|
110 |
|
|
|
|
Ⅱ |
5 |
BAZ51-N150 |
|
150 |
Exd Ⅱ BT6 |
|
|
|
Ⅲ |
5.5 |
BAZ51-N250 |
220 |
250 |
*Exd Ⅱ CT5 |
IP54 |
10～14 |
3/4 |
Ⅲ |
6.5 |
BAZ51-N400 |
|
400 |
*Exe Ⅱ T4 |
*IP55 |
|
|
Ⅲ |
8 |
BAZ51-L100 |
|
100 |
|
|
|
|
Ⅱ |
5.5 |
BAZ51-L175 |
|
175 |
|
|
|
|
Ⅲ |
6 |
BAZ51-L250 |
|
250 |
|
|
|
|
Ⅲ |
6.5 |
BAZ51-L400 |
|
400 |
|
|
|
|
Ⅲ |
8 |
|
| |
|
| IIB類增安型尺寸見下表 IIB Group safety-increased dimension as follow |
|
外殼類型 |
尺寸 |
A |
B |
C |
D |
E |
F |
Ⅰ |
170 |
254 |
190 |
170 |
108 |
46 |
Ⅱ |
216 |
275 |
270 |
240 |
127 |
50 |
Ⅲ |
224 |
306 |
300 |
270 |
136 |
60 |
|
|
| |
|
| |
|
| |
|
