適用范圍
1、1區、2區危險場所。
2、IIA、IIB、IIC類爆炸性氣體環境。

Application
1、Can be used in Zone 1 and Zone 2 dangerous places.
2、Can be used in IIA、IIB、IIC group explosive atmosphere.

產品特點
1、可用于380/220V及以下電路中作為連接各種電氣設備的
分線、接線用，也可作為自控或通訊的信號電源的連線。
2、外殼采用高強度難燃工程塑料壓制而成，外形美觀且具
有抗靜電耐沖擊及熱穩定性好又耐腐蝕等優良性能。
3、蓋與殼身之間設有密封圈，并用不銹鋼螺釘緊固。
4、接線端子可采用壓線式或菲尼克斯的增安型專用接線端
子。
5、端子數出線口方向及數量，公稱直徑可任意變化。
6、符合GB3836-2000，IEC60079標準要求。

Features
1、It is used to sub-connect or connect 380/220V and below electrical circuits, and also applicable to connect supply wire of self-
control engineering or communicaton’s signals.
2、The shell is made of high rigid, flame-proof engineering plastic with beautiful appearance, functions of electrostatic-resistant,
impulsion-withstanding, thermal stability and corrosion-proofing.etc.
3、Between cover and shell body is arranged seal washer fastened by stainless screw.
4、Terminal can be selected for line pressed type of pheonix’s special terminal of safety-increased type.
5、Terminal number, direction, nominal diameter may be changable.
6、Suitable for GB3836-2000, IEC60079 standard request.
