適用范圍
1、1區、2區危險場所。
2、ⅡA、ⅡB、ⅡC類爆炸性氣體環境。

Application
1、Can be used in Zone 1 and Zone 2 dangerous places.
2、Can be used in ⅡA、ⅡB、ⅡC group explosive atmosphere.

產品特點
1、外殼采用高強度難燃工程塑料壓制而成，外形美觀且有抗靜電耐沖擊及熱穩定性好又耐腐蝕等優良性能。
2、具有聯鎖結構，只有插座內的開關分?jǐn)嗪蠓侥馨纬霾孱^。
3、插座上設有掛鎖，在不使用時，可通過掛鎖鎖定，可使插座罩蓋無法打開，便于現場監控。
4、鋼管或電纜布線均可。
＊注：1、連接器作為電纜遠距離連接之用。 2、連接器電流僅限于16A。
5、符合GB3836-2000，IEC60079標準要求。

Features
1、 The shell is made of high rigid, flame-proof engineering plastic with aesthetic outline, functions of electrostatic-resistant, impulsion-withstanding,
thermal stability and corrosion-proofing.
2、With interlocks, only if the switch inside socket is off, the plug can be brought out.
3、 Provision is made to offer padlock on socket. If out of operation, the socket cover can’t be opened by pad lock, so that local inspection and
witnss are easy.
4、Suitable for steel pipe and cable wiring.
*Note：1、Link used for connecting distance-cable. 2、Link’s current is only limited to 16A.
5、Suitable for GB3836-2000, IEC60079 standard request.
