適用范圍
1、爆炸性氣體環境：1區、2區
2、場所中危險氣體或蒸氣：IIA、IIB、IIC
3、溫度組別：T1～T6
4、戶內、戶外（防護等級IP44, 可達IP65)
產品特點
1、適用于控制多臺電動機，可作為照明或儀表配電
2、鋼板焊接制造而成，表面噴塑
3、內裝電器元件可根據用戶要求特制
4、可在箱面操作或遠程操作，也可兩地操作
5、可增加狀態指示燈
6、進出線腔、電器元件器可分別獨立
7、輸入：3P+N+PE 輸出：3P+N+PE
8、可鋼管或電纜布線，電纜布線須配電纜夾緊密封接頭
9、可根據用戶要求特制
|
|
Applying scope
1、Explosive gas atmospheres:Zone 1＆2
2、Dangerous gases or vapors zone: IIA、IIB、IIC
3、Temperature classes:T1～T6
4、 Indoor and outdoor (IP 44,It could be designed as IP65 according to user′s requirements)
Features
1、Kx flame proof control boxes are used to control multiple motors,and to distribute power for lighting or instruments
2、Enclosure is made of steel plate,surface is sprayed with plastics
3、Built-in electrical apparatus can be made to order
4、It can be panel and / or remote controlled
5、Indicating lamps can be added
6、Inlet,outlet compartment and component compartment are independent from each other
7、Input and output: 3P+N+PE
8、Wiring with conduit or cable,For cable, it should be fitted with explosion-protected cable sealing connector
9、For user′s requirements, it could be specially made |
